Mobile device of BOP







The main characteristic of pneumatic pressure testing machine:

Pneumatic pressure testing machine is widely suitable for all kinds of fittings, valve, hose and hard tube, high pressure (uhp) containers and equipment such as pressure vessel pressure and leak test and inspection, especially for oil and gas well drilling engineering using wellhead spray equipment and connection manifold, valve, a pressure test to use, also suitable for scientific research, industry, chemical industry department as a fluid pressure detection tools.



> > technical features:

working medium is water or oil, adaptation range is extensive;

small volume, light weight;

advanced structure, simple operation, mobile and flexible, convenient maintenance;

the main parts adopt imported components, safe and reliable;

low voltage large flow, booster fast, high pressure flow is small, high pressure;

the double pump double control functions can be high and low pressure switch

configuration chart recorder, in can show the pressure at the same time for continuous record of the change in pressure.



>>Product type and specification:

Type

Form a complete set of pneumatic pump
(Ea.)

Pneumatic pump rate
(mL/At times

The origin of pressure(MPa

Gas consumption
(m³/MIN

Work pressure(MPa

Shape (length * width * height)(mm

Weight
(Kg)

QST70

1:30pump×1

180

0.7

1.5

70

1000×725×1050

250

QST70-J

1:100pump×1

30

0.7

1.5

70

1000×725×1050

250

QST140

1:60pump×1

90

0.7

1.5

140

993×866×1280

320

QST140-J

1:200pump×1

13

0.7

1.5

140

993×866×1280

320

QST140B

1:60pump×1

90

0.7

1.5

140

534×530×975

105

QST140B-J

1:200pump×1

13

0.7

1.5

140

534×530×975

105

QST140A

1:60pump×2

90×2

0.7

3

140

1160×866×1325

400

QST140A-J

1:200pump×2

13×2

0.7

3

140

1160×866×1325

400

QST200

1:60pump×1

90

0.9

1.5

200

993×866×1280

320

QST200-J

1:225pump×1

13

0.9

1.5

200

993×866×1280

320

QST200A

1:60pump×2

90×2

0.9

3

200

993×866×1280

400

QST200A-J

1:225pump×2

13×2

0.9

3

200

993×866×1280

400
